NVC TT

MM/MC phono preamplifier

מידע נוסף

מותג	Naim Audio

NVC TT

Get the most out of your vinyl with NVC TT. Very easy to use, it is perfectly compatible with any turntable with MC cartridges and MM cartridges, and easily connects to NAC 332 or NSC 222 preamplifiers. When linked with its dedicated power supply, NPX TT, it offers high performance.

Naim know-how

Under the leadership of our Technical Director, our engineers have developed specific electronic circuits to give the New Classic products superior performance. The best audiophile components have been chosen for NVC TT and highly precise measurements to achieve an uncompromising result. It is an innovative concept, which partly uses the association between the phono stage and the power supply like in Naim’s Solstice Special Edition.

Perfect integration in a complete system

NVC TT connects easily to preamplifiers NSC 222 and NAC 332 from the New Classic range. It has a dedicated power supply, NPX TT, for the ultimate vinyl listening experience.

A timeless design

Naim products are designed to be both contemporary and timeless. Our creations forgo any unnecessary adornments that would detract from the performance and sound quality delivered. The design of NVT TT is inspired by previous Naim creations, such as the SuperLine, but also the Statement amplifier. It is razor sharp, combining a sleek design, premium materials and adjustable logo brightness.

The story of Naim and aluminium

Our founder, Julian Vereker, immediately understood the many benefits of aluminium for wrapping Naim electronic components. He knew that delicate audio components are very sensitive to the effects of magnetic fields, thermal instability, unwanted vibrations, etc.

Specifications

Product Type

Switchable MM/MC phono stage with MC load adjustment

Audio Outputs

Max output signal: 8 Vrms

Headroom:
MM: 22dB ref 5mV input
MC (low & high gain): 23dB ref 0.5mV input low gain setting, 17dB ref 0.5mV high gain setting

Audio Inputs

MM: (Partial) – 2dB at 20Hz and -3dB at 14Hz

Audio Inputs
Power Amp In	+/-18V DC @300mA

Audio Outputs
Powered Accessory Sockets	Stereo RCA
Crosstalk	MM: >75dB
THD + N	MM: <0.005% ref 50mV input MC (low & high gain): <0.005% ref 1.5mV inpu
Signal-to-Noise Ratio	MM: 83dB réf. 5 mV A-wtd MC (low & high gain): 84dB ref 0.5mV A-wtd (both gain settings)
Gain	MM: 42dB MC (low & high gain): 61dB low gain and 67dB high gain (switchable)

Phono Specific
RIAA Accuracy	MM: +/-0.1dB

Physical
Weight	7.5lbs (3.4kg)
Dimensions (HxWxD)	23/4x 83/8x 121/2" (7×21.4×31.7cm)

Power
Amplifier Output	1 x Stereo RCA 1 x 5 pin DIN 1 x 8 pin DIN
Power Output	MM: 47kΩ and 100pF MC (low & high gain): 16 selectable resistive values: 1 000 Ω, 600 Ω, 430 Ω, 330 Ω, 250 Ω, 215 Ω, 185 Ω,165 Ω,150 Ω, 140 Ω, 125 Ω, 115 Ω, 105 Ω, 100 Ω, 90 Ω, 85 Ω 16 selectable capacitive values: 100 pF, 400 pF, 700 pF, 1000 pF, 1300 pF, 1600 pF, 1900 pF, 2200 pF, 2500 pF, 2700 pF, 3100 pF, 3400 pF, 3700 pF, 4000 pF, 4300 pF, 4600 pF

Upgrades
Power Supply	Type 1

מידות

13,000.00 ₪
