Uniti Core

מידע נוסף

מותג	Naim Audio

Uniti Core is the ultimate music manager, able to create bit-perfect copies of your favourite CDs and serve them and the rest of your digital music collection up to music players around your home. Simply load a CD and Uniti Core will expertly rip and catalogue your music. Choose from a range of internal and external storage options for your new digital library. Uniti Core is the perfect music-server partner not just for the Uniti Atom, Uniti Star and Uniti Nova players, but many other music-streaming players, speaker or systems, from Naim and beyond. It can stream to up to 12 different players at once. As well as being a sleek music archivist and server, Uniti Core can also act as a superb music source. Award-winning performance combines with excellent build quality and usability, wrapped in a beautiful British design that will give you years of entertainment. Master the Uniti Core and explore a world of music via the Naim App.

Rip, store, serve and play your music

UPnP^™ (Universal Plug ‘n’ Play)
CD Ripping
Digital Output
Storage and Back up
File Formats
Wireless Updates

So much more than a music server

Easy App control – in one room or many

The Naim App – available for Apple and Android devices – makes it simple to control your Uniti Core, and even link up other music systems around your home into a stunning multi-room set-up.
Use the App to access all your music, including your favourite radio stations, streaming services and playlists, and explore artist discographies and biographies.

Dimensions and Weight

95 mm x 214 mm x 265 mm (H x W x D)
7 kg

Connectivity

Audio Inputs
2 x USB Type A socket (front and rear)

Audio Outputs
1 x BNC S/PDIF

Specifications

Audio Inputs
USB	2 x USB Type A Socket (front and rear)

Audio Outputs
Digital (S/PDIF)	1 x BNC S/PDIF S/PDIF output plays up to 192kHz 352.8kHz and 384kHz are down sampled to 176.4kHz and 192kHz respectively

Certification and Licenses
Certification	Rovi, NTFS, HFS+

Connectivity
Multiroom	Serve up to 4 network-connected players via UPnP™ at full CD quality. Party Mode Streaming: Sync up to six Uniti all-in-one players or other Naim streamers and control via the Naim app.
Multiroom	Serve up to 12 network-connected players via UPnP™. Music stored locally on Uniti Core: 384k 32-Bit WAV, 24576kb/s: <3 streams 384k 24-Bit WAV, 18232kb/s: <5 streams 192k 24-Bit WAV, 9216kb/s: >12 streams 44.1k 16-Bit WAV, 1411kb/s: >16 streams Music stored on a NAS: 192k 24-Bit WAV, 9216kb/s: <8 streams
Updates	Update your system wirelessly via the Naim app.
Network	Ethernet (10/100/1000Mbps)

Formats
CD Formats	Audio CD (Red Book, CD and CD-R)
Audio Formats	WAV – up to 32bits/384kHz FLAC and AIFF – up to 24bit/384kHz ALAC (Apple Lossless) – up to 24bit/384kHz MP3 – up to 48kHz, 320kbit (16 bit) AAC – up to 48kHz, 320kbit (16 bit) OGG and WMA – up to 48kHz (16 bit) DSD – 64 and 128FsNotes: Gapless playback supported on all formats.

Physical
Dimensions	95mm x 214mm x 265mm (HxWxD)
Finishes	Brushed and anodised aluminium
Weight	7kg

Power
Auto Standby time	User selectable: adjustable from off up to 24 hours
Mains Supply	115V, 230V; 50 or 60Hz
Power Consumption	Typical Use (no storage attached): 6.7W Network Standby (no storage attached): <2W Deep Sleep: <0.5W Network Standby (with internal or USB HDD attached): > 15W. Actual power consumption will vary depending on the size and type of attached internal HDD or USB devicesNote: Power consumption will be increased with the addition of user fitted storage (typical increase of approximately 8W for an internal HDD, dependant on the specification of storage).

Ripping and Storage
CD Ripping	Create bit-perfect copies of your CDs, store them internally and play back (external DAC or digital input amplifier needed).
Storage	Store up to 100,000 tracks to internal (HDD or SSD – up to 6TB) or external Network Attached Storage or USB-connected storage and serve to a network-connected player.

Supplied with
Supplied with	Power-Line Lite mains cable (UK only), standard mains cable (international markets), cleaning cloth, drive caddy screws, BNC to Phono Connector and quick start guide. Please note: not sold with an internal hard drive – features a removable caddy into which an HDD or SSD can be installed
